Model
|
YF-30RW
|
|
Excavaor（ton）
|
20~30
|
|
Max Power Output (kw)
|
110
|
|
Max Flow (lpm)
|
350
|
|
Recommended Flow (lpm)
|
200-300
|
|
Pressure (bar)
|
315
|
|
Output Torque (bar)
|
21155Nm@315
|
|
Output Shaft Speed (lpm)
|
71rpm@300
|
|
Weight (kgs)
|
1800
|
|
Cutter Bit (pcs)
|
64
|
15+ Years of Expertise in the Excavator Attachment Industry.
Feel free to contact me for any inquiries or professional support.
Model |
YF -02RW |
YF -05RW |
YF-10RW |
YF-15RW |
Excavaor（ton） |
0.7~2.5 |
2.5~6 |
5~10 |
10~15 |
Max Power Output (kw) |
16 |
22 |
36 |
50 |
Max Flow (lpm) |
45 |
65 |
112 |
150 |
Recommended Flow (lpm) |
20-40 |
40-60 |
60-100 |
60-140 |
Pressure (bar) |
315 |
315 |
315 |
315 |
Output Torque (bar) |
1592Nm@315 |
3780Nm@315 |
6440Nm@315 |
8455Nm@315 |
Output Shaft Speed (lpm) |
100rpm@40 |
80rpm@60 |
80rpm@100 |
82rpm@140 |
Weight (kgs) |
145 |
215 |
381 |
720 |
Cutter Bit (pcs) |
44 |
56 |
64 |
68 |
Model |
YF-20RW |
YF-30RW |
YF-40RW |
YF-50RW |
Excavaor（ton） |
15~20 |
20~30 |
30~50 |
50~70 |
Max Power Output (kw) |
80 |
110 |
140 |
175 |
Max Flow (lpm) |
250 |
350 |
450 |
550 |
Recommended Flow (lpm) |
140-220 |
200-300 |
300-400 |
400-500 |
Pressure (bar) |
315 |
315 |
315 |
315 |
Output Torque (bar) |
14170Nm@315 |
21155Nm@315 |
30300Nm@315 |
50495Nm@315 |
Output Shaft Speed (lpm) |
78rpm@220 |
71rpm@300 |
66rpm@400 |
50rpm@500 |
Weight (kgs) |
1370 |
1800 |
2400 |
5200 |
Cutter Bit (pcs) |
80 |
64 |
72 |
68 |
