Model
|
YAH-10C
|
|
Max. Output Torque （N.m）
|
100000
|
|
Base Machine Weight （ton）
|
32 - 52
|
|
Pressue（Bar）
|
250 - 300
|
|
Flow（LPM）
|
300 - 477
|
|
Speed （rpm）
|
0 -15
|
|
Torque Measuring Range（N.m）
|
100000
|
|
Safe Overload of Torque Indicator
|
150% F.S.
|
|
Tilt Measuring Range
|
X: ±180°
Y: ±90° Z: ±180° |
|
Tilt Measuring Accuracy
|
0.1°
|
|
Operating Temp Range
|
-20℃ TO 80℃
|
|
Data Transmission
|
Wireless
|
|
Protection Class
|
IP66
|
|
Power
|
Lithium Battery
|
28
Aug
28
Aug
28
Aug
28
Aug
The installation was incredibly fast and clean, with almost no vibration or excavation needed. We kept the entire site operational, which our client loved.
Choosing helical piles over a concrete foundation saved us nearly 20% on the project and cut weeks off our timeline. The ROI was immediate.
